Key Specifications
• Ports: 5 × 10/100 Mbps Ethernet ports (Ports 1 and 2 support WPoE power supply and data transmission with compatible WECON devices; Ports 3 to 5 support standard Ethernet).
• Power Supply: 24V DC (14V to 24V / 18V to 28V range depending on spec), load power under 10W.
• Dimensions: 113.1 × 71.0 × 29.0 mm (L × W × H) in a compact iron metal housing.
• Mounting: Standard 35 mm DIN rail and wall mounting.
• VLAN Isolation: Built-in VLAN isolation function splits the ports into separate local networks for safer data communication.
