Name: LX3V-2WT
Brand: WECON
Price: 19200 INR
Availability: InStock

Phone Number

08048036809

Please keep 0 before dialling the number.

Email Address info@adhiraautomation.com

Mon-Thu: 10 AM - 2 PM • Fri: 3 PM - 7AM

Other Website Visit our other website

Address 42, Maruthamalai Gounder Layout, Ramakrishnapuram, Ganapathy, Coimbatore - 641006. Tamilnadu, South India

Coimbatore, India, 641006

Description

The WECON LX3V-2WT is a 2-channel, 24-bit high-precision weighing module designed for LX3V or LX5V series PLCs. It supports load cell signals, 4- or 6-wire configurations, and offers adjustable sampling speeds ((7.5)–(300text{Hz})) with high accuracy for industrial applications. Key Features and Specifications: Channels: 2-channel independent, isolated input.Resolution & Accuracy: 24-bit high-precision A/D converter with (le 0.01%) full-scale non-linearity.Speed: Selectable sampling rates of 7.5/10/25/50/60/150/300 Hz.Sensor Input: Supports unipolar and bipolar signals; 1mV/V–15mV/V sensitivity.Excitation Voltage: 5V DC, suitable for load impedances (ge 200Omega ).Interface: Connects to PLC using FROM/TO instructions.Functions: Supports tare, net weight calculations, and digital filtering.Power: 24V DC ((pm 20%)). The module is commonly used for weight measurement, filling, and batching systems via DIN-rail mounting.
